Object
Port Members
VLAN Membership
Buttons
• Select VLAN Users
• Select the Auto-refresh
refresh occurs every three seconds.
• Click Refresh to refresh the page immediately.
• Click I<< to update the table starting from the first entry in the VLAN Table (i.e., the
entry with the lowest VLAN ID).
• Click >> to update the table, starting with the entry after the last entry currently
displayed.
VLAN port status
The VLAN Port Status for Combined users page provides VLAN port status.
142
Description
GVRP : GVRP (GARP VLAN Registration Protocol or Generic VLAN
Registration Protocol) is a protocol that facilitates control of virtual
local area networks (VLANs) within a larger network .
Voice VLAN : Voice VLAN is a VLAN configured specially for voice
traffic typically originating from IP phones.
MVR : MVR is used to eliminate the need to duplicate multicast traffic
for subscribers in each VLAN. Multicast traffic for all channels is sent
only on a single (multicast) VLAN.
A row of check boxes for each port appears for each VLAN ID.
If a port is included in a VLAN, an image
If a port is included in a Forbidden port list, an image
If a port is included in a Forbidden port list and dynamic VLAN user
register VLAN on same Forbidden port, then the conflict port appears
as a conflict port.
The VLAN Membership Status Page shows the current VLAN port
members for all VLANs configured by a selected VLAN user
(selection shall be allowed by a Combo Box). When ALL VLAN users
are selected, it shows this information for all the VLAN users by
default. VLAN membership allows the frames classified to the VLAN
ID to be forwarded on the respective VLAN member ports.
from the Combined
check box to refresh the page automatically. Automatic
drop-down list.
