Chapter 4: Web configuration
Buttons
• Click Add New Entry
• Click Apply to apply changes.
• Click Reset to undo any changes made locally and revert to previously saved
values.
• Select the Auto-refresh
refresh occurs every three seconds.
• Click Refresh to refresh the page immediately.
Protocol-based VLAN membership
The Group Name to VLAN Mapping Table page permits mapping an already configured
Group Name to a VLAN.
The page includes the following fields:
Object
Delete
Group Name
VLAN ID
Port Members
Adding a New Group
to VLAN mapping
entry
158
to add a new MAC-based VLAN entry
check box to refresh the page automatically. Automatic
Description
Select this box to delete a Group Name to VLAN map entry. The entry will be
deleted on the switch during the next save.
A valid Group Name is a unique 16-character long string for every entry
which consists of a combination of alphabets (a-z or A-Z) and integers (0-9).
No special character is allowed. Whichever group name you try map to a
VLAN must be present in the Protocol to Group mapping table and must not
be used by any other existing mapping entry on this page.
Indicates the ID to which the group name will be mapped. A valid VLAN ID
ranges from 1-4095.
A row of check boxes for each port is displayed for each group name to
VLAN ID mapping. To include a port in a mapping, select the box. To
remove or exclude the port from the mapping, make sure the box is
deselected. By default, no ports are members, and all boxes are deselected.
Click the Add New Entry
is added to the table, and Frame Type, Value, and the Group Name can be
configured as needed.
Click the Delete button to undo the addition of a new entry.
to add a new entry in mapping table. An empty row
