Chapter 4: Web configuration
The page includes the following fields:
Object
Aggr ID
Name
Type
Speed
Configured Ports
Aggregated Ports
Aggr ID
Buttons
• Click Refresh to refresh the page immediately.
LACP configuration
LACP LAG negotiates aggregated port links with other LACP ports located on a
different device. LACP allows switches connected to each other to discover
automatically whether any ports are member of the same LAG.
This page allows the user to inspect and change the current LACP port configurations.
The LACP port settings relate to the current device, as reflected by the page header.
126
Description
The aggregation ID associated with this aggregation instance.
Name of the aggregation group ID.
Type of the aggregation group (static or LACP).
Speed of the aggregation group.
Configured member ports of the aggregation group.
Aggregated member ports of the aggregation group.
The aggregation ID associated with this aggregation instance.
