ifs NS4702-24P-4X-V2 User Manual page 25

Access Control List
Bandwidth Control
Layer 3 Functions
IP Interfaces
Routing Table
Routing Protocols
Management
Basic Management Interfaces Console, Telnet, web browser, SNMP v1, v2c
Secure Management
Interfaces
SNMP MIBs
Standards Conformance
Regulation Compliance
Standards Compliance
Environment
Operating
Storage
NS4702-24P-4X-V2 Managed Switch User Manual
MLD querier mode support
IP-based ACL / MAC-based ACL
Up to 256 entries
Per port bandwidth control
– Ingress: 100 Kbps~1000 Mbps
– Egress: 100 Kbps~1000 Mbps
Maximum of eight VLAN interfaces
Maximum of 32 routing entries
IPv4 software static routing
IPv6 software static routing
SSH, SSL, SNMP v3
RFC-1213 MIB-II
RFC-1493 Bridge MIB
RFC-1643 Ethernet MIB
RFC-2863 Interface MIB
RFC-2665 Ether-Like MIB
RFC-2819 RMON MIB (Group 1, 2, 3 and 9)
RFC-2737 Entity MIB
FCC Part 15 Class A, CE
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX/100BASE-FX
IEEE 802.3z Gigabit SX/LX
IEEE 802.3ab Gigabit 1000T
IEEE 802.3ae 10Gb/s Ethernet
IEEE 802.3x flow control and back pressure
IEEE 802.3ad port trunk with LACP
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
IEEE 802.1s Multiple Spanning Tree Protocol
IEEE 802.1p Class of Service
Temperature: 0 to 50°C
Relative Humidity: 5 to 95% (non-condensing)
Temperature: -10 to 70°C
Relative Humidity: 5 to 95% (non-condensing)
Chapter 1: Introduction
21
