• SMTP/Syslog remote alarm
• SNMP trap for interface Link Up and Link Down notification
• System log
• Smart fan with speed control

Product specifications

Hardware Specifications
Copper Ports
SFP+ Slots
Console Port
Switch Architecture
Switch Fabric
Throughput
Address Table
Shared Data Buffer
Flow Control
Jumbo Frame
Reset Button
LED
Dimensions (W x D x H)
Weight
Power Consumption
Power Requirement
ESD Protection
NS4702-24P-4X-V2 Managed Switch User Manual
24 10/ 100/1000BASE-T RJ45 auto-MDI/MDI-X ports
Four 10GBASE-SR/LR SFP+ interfaces (Port-25 to Port-28)
Compatible with 1000BASE-SX/LX/BX SFP transceiver
1 x RS-232 to RJ45 serial port (115200, 8, N, 1)
Store-and-Forward
128 Gbps / non-blocking
95.23 Mpps @ 64 bytes
16K entries, automatic source address learning and aging
32M bits
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
10K bytes
< 5 seconds: System reboot
> 5 seconds: Factory Default
System:
SYS (Green)
AC/PWR (Green)
Fan1/2/3 Alert (Red)
PoE PWR Alert (Red)
PoE Ethernet Interfaces (Port-1 to Port-24):
PoE In-use (Orange)
Ethernet Interfaces (Port-1 to Port-24):
1000 LNK/ACT (Green), 10/100 LNK/ACT (Orange)
1/10G SFP+ Interfaces (Port-25 to Port-28):
1G (Green), 10G (Orange)
440 x 300 x 56 mm, 1.25U height
4.64 kg
Max. 488 W / 1665.13 BTU
AC 100~240 V, 50/60 Hz, 7 A
6K VDC
