Features

Table 1 describes the features available on the Mars EB1 base board.
Feature Description
Form factor 120
System features System controller
Built-in Xilinx JTAG (via USB connection)
System monitor
Power control
Current sense
Memory microSD card holder
User EEPROM
Connectors USB 2.0 host connector
2
FTDI USB 2.0 High-Speed device controller
RJ45 Gigabit Ethernet connector
2
HDMI 1.3 connector
User I/Os 40-pin Anios pin header
3
Supply voltage 12 V DC (internal, external)
USB-power (with restrictions)
Table 1: Base Board Features
Warning!
Please note that the available features depend on the equipped Mars FPGA/SoC module.
3.3

Board Configuration and Product Models

Table 2 describes the standard base board configurations. Custom configurations are available; please
contact Enclustra for further information.
2
Requires FPGA support (video protocol implementation)
D-0000-307-001
80 mm
micro USB device connectors (one connector is shared with the USB 2.0 host)
Mini Camera Link connectors
2
12-pin pin headers (from which 2
2
Pmod™ compatible)
