Features

Table 1 describes the features available on the Mercury+ PE3 base board. The available features depend
on the mounted Mercury FPGA/SoC module.
Feature
Form factor
Module connector
System features
Memory
Connectors
Continued on next page...
D‐0000‐420‐001
Description
171 112.4 mm
3 Number of 168‐pin Hirose FX10 connectors
System controller
Built‐in USB support for AMD JTAG, SPI flash programming and UART and IC2
System monitor
Power control
Current sense
Flexible MGT routing between Mercury connector and MGT capable endpoints
Low‐jitter clock generator
Programmable user oscillator ﴾optional﴿
1 Custom clock inputs ﴾micro‐coaxial connection﴿
7 Status LEDs
Battery holder to supply RTC on module
microSD card holder
User EEPROM
PCIe 8 interface
QSFP+ slot
4 SFP+ slots ﴾only for ME‐PE3‐4S‐C product model﴿
HDMI 2.0a connector
USB Type‐C connector
USB 3.0 host interface
Micro USB 2.0 device ﴾UART, SPI, I2C, JTAG﴿ interface
2 Ethernet RJ45 connectors
M.2 SATA/NVMe slot
FireFly connector
FMC HPC connector
JTAG connector
