7 Operating Conditions

7.1

Absolute Maximum Ratings

Table 32 indicates the absolute maximum ratings for Mars EB1 base board.
Symbol Description
VCC_12V_IN Supply voltage relative to GND
VCC_IO_[x] VCC I/O input voltage relative to GND
Ambient temperature range for commercial boards (C)
T
ambient
Ambient temperature range for wide range boards (W)
T Storage temperature
stor
Table 32: Absolute Maximum Ratings
7.2

Recommended Operating Conditions

Table 33 indicates the recommended operating conditions for Mars EB1 base board.
Symbol Description
VCC_12V_IN Supply voltage relative to GND
VCC_IO_[x] VCC I/O input voltage relative to GND
Ambient temperature range for commercial boards (C)
T
ambient
Ambient temperature range for wide range boards (W)
T Storage temperature
stor
Table 33: Recommended Operating Conditions
Warning!
*
The components used on the hardware are specified for the relevant temperature range. The user
must provide adequate cooling in order to keep the temperature of the components within the specified
range.
D-0000-307-001
*
*
36 / 39
Rating
-0.5 to 16
Refer to the Mars
module user manual
0 to +70
*
-25 to +85
-25 to +85
Rating
5 to 12
Refer to the Mars
module user manual
0 to +70
*
-25 to +85
-25 to +85
Version 06, 22.07.2021
Unit
V
C
C
C
Unit
V
C
C
C
