Table 10 shows an example of a mating part for the fan/internal power connector.
Type
61900311621
Table 10: Mating Part for the Fan/Internal Power Connector
4.3

I/O Voltage Selection (J1200)

The I/O voltage selection jumpers are used to configure the VCC_IO_A and VCC_IO_B voltages that power
the I/O banks of the SoC/FPGA device on the Mars module. Refer to Section 5.5 for details.
4.4

Mars Module Connector (J200)

A detailed pinout of the Mars module connector can be found in the Mars Master Pinout [10] and in the
Mars EB1 Base Board User Schematics [5].
Table 11 indicates the module connector type.
Height
5.2 mm
Table 11: Module Connector Type
Warning!
Only Enclustra Mars FPGA/SoC modules should be inserted into the Mars EB1 base board.
Warning!
The VCC_IO pins are directly connected to the FPGA/SoC device. Apply only compliant voltages to the
VCC_IO pins; any other voltage may damage the mounted Mars FPGA/SoC module, as well as other
devices on the Mars EB1 base board.
4.5

USB 2.0 Host Connector (J400)

If the mounted Mars module features a USB controller, the module's USB signals can be connected to J400
via a multiplexer. Details on USB connections on the board are available in Section 6.5.
The power and data signals on this connector are ESD-protected.
4.6

Micro USB 2.0 Device Connectors (J401/J402)

There are two micro USB 2.0 device connectors on the Mars EB1 base board: one on the front panel and
one on the side.
D-0000-307-001
Manufacturer
Würth Elektronik
Type
TE 1565917-4
18 / 39
Type
TE Connectivity
Version 06, 22.07.2021
