3.8

Mechanical Data

Table 4 describes the mechanical characteristics of the Mars EB1 base board. A 3D model (PDF) and a STEP
3D model are available [7], [8].
Symbol
Size
Component height top
Component height bottom
Weight
Table 4: Mechanical Data
3.9

Mechanical Components

Table 5 describes the mechanical components present on the Mars EB1 base board. The listed elements are
for reference only. Any other components that meet the requirements may be used.
Product Number
973080365
Table 5: List of Mechanical Components
D-0000-307-001
Value
120 80 mm
14.4 mm
4 mm
60 g
Manufacturer Description
Würth Elektronik 4 plastic spacer bolt with female thread/clip, length 8 mm
16 / 39 Version 06, 22.07.2021
