Summary of Contents for Enclustra MERCURY XU5

  • Page 1 MERCURY XU5 Design-In Kit Quick Start Guide...
  • Page 2: What's In The Box

    What’s in the Box – Mercury XU5 module – MiniDP to DP cable – Mercury+ ST1 – Micro SD card base board – Example designs: – USB camera AI face detection and – Heatsink image classification – Fan based on ResNet50 –...
  • Page 3 The Design-In Kit Mercury XU5 System-on-Module (SOM) Bottom view view Mercury+ ST1 Base Board...
  • Page 4: Set Up The Hardware

    Set up the Hardware Mount the module and the heatsink to the base board Connect the Base Board 1. Insert module first. 2. Follow the steps in the order indicated in the image below. 3. Insert power last. 1 Set/check jumpers VSEL 1 2 3 4...
  • Page 5 Run the Demos Preparation: – Prepare and connect the board according to the hardware setup instructions (see «Set up the Hardware»). – Open a terminal program on your computer (e.g. Tera Term) and open a serial port connection using the COM port labeled with the higher number from the two newly detected ports.
  • Page 6 Enclustra GmbH Räffelstrasse 28 8045 Zürich Switzerland +41 43 343 39 43 info@enclustra.com www.enclustra.com...
