6.2

Buttons

All buttons are active-low; their function is described in Table 21.
The user buttons can be configured by the user to have various functions. For details, refer to Section 6.10
and to the Mars EB1 Base Board User Schematics [5].
Button
Name Button
PWR S1300
POR S1205
SRST S1202
0 S1203
1 S1204
Table 21: Board Buttons
D-0000-307-001
Signal Name
PWR_BTN#
POR#_LOAD#
SRST#_RDY#
IOC_D0_SC0_BTN0#
IOC_D1_SC1_BTN1#
Function
Power on/off
Power-on reset/
Configuration-clear
Soft-reset/
Configuration-delay
User function
User function
28 / 39
Comments
Refer to Section 5.3
Refer to the Enclustra Module Pin
Connection Guidelines [9]
Refer to the Enclustra Module Pin
Connection Guidelines [9]
Shared with the system controller,
module connector and PMOD I/O
connector C
Shared with the system controller,
module connector and PMOD I/O
connector C
Version 06, 22.07.2021
