Product Model
MA-EB1-W
Table 2: Standard Base Board Configurations
3.4 EN-Numbers and Part Names
Every board is uniquely labeled, showing the EN-number and serial number. An example is presented in
Figure 2.
Figure 2: Product Label
The correspondence between EN-number and part name is shown in Table 3. The part name represents the
product model, followed by the revision; the R suffix and number represent the revision number.
The revision changes and product known issues are described in the Mars EB1 Base Board Known Issues and
Changes document [6].
EN-Number Part Name
EN100785 MA-EB1-W-R1
EN100786 MA-EB1-C-R1
EN100861 MA-EB1-W-R2
EN100906 MA-EB1-C-R2
EN103052 MA-EB1-W-R2.5
Table 3: EN-Numbers and Part Names
D-0000-307-001
Features
Refer to Table 1
10 / 39
Temperature Range
-25..+85 C
