Ensure that the power supply is disconnected from the board before inserting or removing a Mars module,
connecting interfaces, or connecting jumpers.
Touching the capacitors of the DC-DC converters can lead to voltage peaks and permanent damage; over-
voltage on power or signal lines can also cause permanent damage to the board and to the equipped
module.
1.1.6

Electrostatic Discharge

Electronic boards are sensitive to electrostatic discharge (ESD). Please ensure that the product is handled
with care and only in an ESD-protected environment.
1.1.7

Electromagnetic Compatibility

The Mars EB1 base board is a Class A product (as defined in IEC 61000-3-2 standard) and is not intended for
use in domestic environments. The product may cause electromagnetic interference, for which appropriate
measures must be taken.
1.2

Deliverables

Mars EB1 base board
Mars EB1 base board documentation, available via download:
Mars EB1 Base Board User Manual (this document)
Mars EB1 Base Board IO Net Length Excel Sheet [4]
Mars EB1 Base Board User Schematics (PDF) [5]
Mars EB1 Base Board Known Issues and Changes [6]
Mars EB1 Base Board 3D Model (PDF) [7]
Mars EB1 Base Board STEP 3D Model [8]
Mercury Mars Module Pin Connection Guidelines [9]
1.3

Accessories

Mars FPGA or SoC module
12 V DC/2.5 A power supply
USB 2.0 A to micro-B USB cable
D-0000-307-001 6 / 39 Version 06, 22.07.2021
