6 Board Function

6.1

LEDs

LED
Name LED Signal Name
PWGD D1201 PWR_OK#
DONE D1200 FPGA_DONE
RX D1202 NOR_MISO_RXLED#
TX D1203 NOR_MOSI_TXLED#
CPU D1204 NOR_CLK_CPULED#
SC D1205 NOR_CS#_SCLED#
Table 20: Board LEDs
For details on the LED connections, refer to Section 6.10 and to the Mars EB1 Base Board User Schematics
[5].
D-0000-307-001
Controlled by Description
Power circuits Indicates that PWR_GOOD is active and
VCC_IO_A and VCC_IO_B are available
Power circuits FPGA configuration is done
System controller UART RX status, shared with SPI NOR flash
MISO signal
System controller UART TX status, shared with SPI NOR flash
MOSI signal
System controller CPU status, shared with SPI NOR flash CLK
signal
System controller System controller status, shared with SPI
NOR flash CS signal
