Mars AX3 FPGA Module
Reference Design for Mars PM3 Base Board
Purpose
The purpose of this document is to present to the user the overall view of the Mars AX3 FPGA module
reference design and to provide the user with a step-by-step guide to the complete Xilinx® FPGA design
flow used for the Mars AX3 FPGA module.
Summary
This document first gives an overview of the Mars AX3 FPGA module reference design and then guides
through the complete Xilinx FPGA design flow for the Mars AX3 FPGA module in the getting started
section. In addition, the internals and the boot options of the Mars AX3 FPGA module reference design
are described.
Product Information
Product
Document Information
Reference / Version / Date
Approval Information
Written by
Verified by
Approved by
User Manual
Code
MA-AX3
Reference
D-0000-492-002
Name
DDUE/ARUD/ESOM
GKOE
IJOS
Enclustra GmbH – Räffelstrasse 28 – CH-8045 Zürich – Switzerland
Name
Mars AX3 FPGA Module
Version
2022.1_v1.0.2
Position
Design Engineer
Design Expert
Manager, BU SP
Phone +41 43 343 39 43 – www.enclustra.com
Date
04.01.2023
Date
30.09.2022
05.10.2022
15.10.2022
