User Eeprom; System Monitor Voltage Connections; System Monitor I/O And Fan Connections; User Eeprom Type - Enclustra Mars EB1 Base Board User Manual

Board
Reference Signal Name
- VMON_MAIN
- VMON_3V3
- VMON_OUT
- VMON_2V5
J200.41 VMON_P41
J200.42 VMON_P42
J200.94 VMON_P94
J200.198 VMON_P198
- VMON_5V
- VMON_CS_MOD
- VREF_CS
Table 28: System Monitor Voltage Connections
Table 29 describes the GPIO and fan connections of the system monitor.
Board Reference
J1302.3
J1101.13
J1101.15
Table 29: System Monitor I/O and Fan Connections
6.8

User EEPROM

The Mars EB1 base board features a user EEPROM which may be accessed via I2C. It can be used to store
user data (e.g. a serial number) and can be accessed by the FPGA and by the system controller.
Type Manufacturer
24AA128T-I/MNY Microchip
Table 30: User EEPROM Type
D-0000-307-001
System
Monitor
Register
IN0
IN1
IN2
IN3
IN0
IN1
IN2
IN3
IN4
IN5
IN6
Signal Name System Monitor Register
SYSMON_TACHO FAN1
SYSMON_GPI GPI(CI)
SYSMON_GPO# GPO#
VMON_SEL Comments
0 5 - 12 V
0 3.3 V
0 VCC_OUT voltage of the module (module
dependent)
0 2.5 V
1 Module dependent
1 Module dependent
1 Module dependent
1 Module dependent
- (don't care) 5 V 10%
- (don't care) VCC_3V3_MOD current
- (don't care) VREF current sensor
34 / 39
5%
5%
Description
Fan speed sense signal
General purpose input
General purpose output
Version 06, 22.07.2021
