Mars ZX3 SoC Module
Reference Design for Mars PM3 Base Board
Purpose
The purpose of this document is to present to the user the overall view of the Mars ZX3 SoC module
reference design and to provide the user with a step-by-step guide to the complete Xilinx® SoC design
flow used for the Mars ZX3 SoC module.
Summary
This document first gives an overview of the Mars ZX3 SoC module reference design and then guides
through the complete Xilinx SoC design flow for the Mars ZX3 SoC module in the getting started sec-
tion. In addition, the internals and the boot options of the Mars ZX3 SoC module reference design are
described.
Product Information
Product
Document Information
Reference / Version / Date
Approval Information
Written by
Verified by
Approved by
User Manual
Code
MA-ZX3
Reference
D-0000-489-005
Name
DDUE/ARUD/ESOM
GKOE
IJOS
Enclustra GmbH – Räffelstrasse 28 – CH-8045 Zürich – Switzerland
Name
Mars ZX3 SoC Module
Version
2022.1_v1.1.2
Position
Design Engineer
Design Expert
Manager, BU SP
Phone +41 43 343 39 43 – www.enclustra.com
Date
15.10.2022
Date
30.09.2022
05.10.2022
15.10.2022
