2 Getting Started

This section contains essential information on using the Mars EB1 base board.
Electrostatic discharge (ESD) may damage the Mars EB1 base board partially or completely. Please follow
the relevant guidelines for ESD-safe handling when operating or assembling electronic components.
Before first use of the Mars EB1 base board with a Mars module, the following steps must be followed:
Mount the module on the module slot on the base board, with the power switched off.
Set the DIP switches correctly (refer to Section 6.3).
Set the I/O voltage selection jumpers correctly (refer to Section 5.5).
Power up the board (refer to Section 5 for power options).
The power supply of the base board must be turned off in the following situations:
Before changing the position of the I/O voltage selection jumpers
Before removing the Mars module
Before connecting or disconnecting peripherals to ANIOS and I/O connectors
Before connecting peripherals, make sure that the corresponding VCC_IO voltage is properly set.
The operating conditions for the Mars EB1 base board and equipped module must conform to the values
given in Section 7, and in the relevant section from the Mars module user manual.
