Mars EB1 Base Board
Purpose
The purpose of this document is to present the characteristics of Mars EB1 base board to the user, and to
provide the user with a comprehensive guide to understanding and using the Mars EB1 base board.
Summary
This document first gives an overview of the Mars EB1 base board followed by a detailed description of its
features and configuration options. In addition, references to other useful documents are included.
Product Information
Product
Document Information
Reference / Version / Date
Approval Information
Written by
Verified by
Approved by
User Manual
Code
MA-EB1
Reference
D-0000-307-001
Name
DIUN, GKOE
GLAC, GKOE, GJER
DIUN
Enclustra GmbH – Räffelstrasse 28 – CH-8045 Zürich – Switzerland
Name
Mars EB1 Base Board
Version
06
Position
Design Engineer
Design Expert
Manager, BU SP
Phone +41 43 343 39 43 – www.enclustra.com
Date
22.07.2021
Date
12.02.2016
22.02.2016
22.07.2021
Advertisement
Chapters
Table of Contents
Related Manuals for Enclustra Mars EB1 Base Board
Summary of Contents for Enclustra Mars EB1 Base Board
- Page 1 User Manual Purpose The purpose of this document is to present the characteristics of Mars EB1 base board to the user, and to provide the user with a comprehensive guide to understanding and using the Mars EB1 base board. Summary This document first gives an overview of the Mars EB1 base board followed by a detailed description of its features and configuration options.
- Page 2 Unauthorized duplication of this document, in whole or in part, by any means is prohibited without the prior written permission of Enclustra GmbH, Switzerland. Although Enclustra GmbH believes that the information included in this publication is correct as of the date of publication, Enclustra GmbH reserves the right to make changes at any time without notice.
-
Page 3: Table Of Contents
Table of Contents Overview General ........... 1.1.1 Introduction . - Page 4 Board Function LEDs ........... . . 27 Buttons .
-
Page 5: Overview
1.1.4 Disposal and WEEE The Mars EB1 base board must be properly disposed of at the end of its life. If a battery is installed on the board, it must also be properly disposed of. The Waste Electrical and Electronic Equipment (WEEE) Directive (2002/96/EC) is not applicable for the Mars EB1 base board. -
Page 6: Electrostatic Discharge
1.1.7 Electromagnetic Compatibility The Mars EB1 base board is a Class A product (as defined in IEC 61000-3-2 standard) and is not intended for use in domestic environments. The product may cause electromagnetic interference, for which appropriate measures must be taken. -
Page 7: Getting Started
ESD-safe handling when operating or assembling electronic components. Before first use of the Mars EB1 base board with a Mars module, the following steps must be followed: Mount the module on the module slot on the base board, with the power switched off. -
Page 8: Board Description
3 Board Description Block Diagram The Mars EB1 base board can be used in combination with any Mars module. The block diagram of the Mars EB1 base board is shown in Figure 1. Figure 1: Hardware Block Diagram D-0000-307-001 8 / 39... -
Page 9: Features
Features Table 1 describes the features available on the Mars EB1 base board. Feature Description Form factor 80 mm System features System controller Built-in Xilinx JTAG (via USB connection) System monitor Power control Current sense Memory microSD card holder User EEPROM Connectors USB 2.0 host connector... -
Page 10: Numbers And Part Names
The correspondence between EN-number and part name is shown in Table 3. The part name represents the product model, followed by the revision; the R suffix and number represent the revision number. The revision changes and product known issues are described in the Mars EB1 Base Board Known Issues and Changes document [6]. -
Page 11: Top And Bottom Views
Top and Bottom Views 3.5.1 Top View Figure 3: Board Top View D-0000-307-001 11 / 39 Version 06, 22.07.2021... -
Page 12: Bottom View
3.5.2 Bottom View Figure 4: Board Bottom View Please note that depending on the hardware revision and configuration, the base board may look slightly different than shown in this document. D-0000-307-001 12 / 39 Version 06, 22.07.2021... -
Page 13: Top And Bottom Assembly Drawings
Top and Bottom Assembly Drawings 3.6.1 Top Assembly Drawing Figure 5: Board Top Assembly Drawing D-0000-307-001 13 / 39 Version 06, 22.07.2021... -
Page 14: Bottom Assembly Drawing
3.6.2 Bottom Assembly Drawing Figure 6: Board Bottom Assembly Drawing Please note that depending on the hardware revision and configuration, the base board may look slightly different than shown in this document. D-0000-307-001 14 / 39 Version 06, 22.07.2021... -
Page 15: Board Dimensions
Board Dimensions Figure 7: Board Dimensions D-0000-307-001 15 / 39 Version 06, 22.07.2021... -
Page 16: Mechanical Data
Mechanical Data Table 4 describes the mechanical characteristics of the Mars EB1 base board. A 3D model (PDF) and a STEP 3D model are available [7], [8]. Symbol Value Size 80 mm Component height top 14.4 mm Component height bottom... -
Page 17: Connectors Description
The inner and outer diameters of the mating plug are 2.0 mm and 5.5 mm respectively. Fan/12 V Internal Power Connector (J1302) The Mars EB1 base board can alternatively be powered through the internal power input connector. The 12 V DC power source connected to J1302 must be filtered by external power circuitry. -
Page 18: I/O Voltage Selection (J1200)
The power and data signals on this connector are ESD-protected. Micro USB 2.0 Device Connectors (J401/J402) There are two micro USB 2.0 device connectors on the Mars EB1 base board: one on the front panel and one on the side. -
Page 19: Gigabit Ethernet Port (J900)
The power and data signals on J401/J402 connectors are ESD-protected. Gigabit Ethernet Port (J900) The Mars EB1 base board is equipped with a 10/100/1000 Mbit Ethernet port. The capability of the Ethernet interface depends on the connected Mars module. The RJ45 connector J900 is connected through magnetics directly to the Mars module connector. For details on the Ethernet interface, refer to Section 6.4. -
Page 20: Microsd Card Slot (J800)
The Anios I/O connector can be used for user applications: it provides 24 user I/Os, a differential clock connection, connectivity to the I2C bus, and power supply connections. The clock, data and I2C signals are routed to the module connector - for details, refer to the Mars EB1 Base Board User Schematics [5]. Warning! The Anios I/O pins are connected directly to the FPGA/SoC device. -
Page 21: I/O Connector D (J1103)
The battery holder and battery are not mounted in the standard configuration of the Mars EB1 base board. The battery on the Mars EB1 base board is used for buffering the real-time clock on the connected Mars FPGA/SoC module. If required, a 3 V lithium battery (CR1220) can be used. -
Page 22: Xilinx Jtag Over System Controller
FPGA/SoC device as well as other devices on the module or Mars EB1 base board. The JTAG connector available on the Mars EB1 base board can be used in combination with Xilinx Platform Cable USB or Intel USB-Blaster download cable. For Xilinx JTAG connection, the flying wire adapter must be used. -
Page 23: J1101 - Control Connector
Pin Number Signal Name Description Function Supply output/ VCC_12V_CM 12 V DC main voltage Monitor Ground Supply output/ VCC_5V 5 V DC-DC converter output Monitor VCC_3V3_SC 3.3 V DC voltage for the system con- Monitor troller power UART_RX_EXT External connection UART RX, config- Control urable via system controller registers See Section 6.10 for details... -
Page 24: Power
USB VBUS power connection Power over USB As soon as a USB cable is plugged into the Mars EB1 base board, the system controller and the FTDI USB 2.0 device controller are powered over USB; this will cause the SC LED to blink. -
Page 25: Power Sequencing
If power control is disabled, the Mars EB1 base board and the mounted module are powered as soon as power is applied through external or internal power connectors. If power control is enabled, the Mars module is not powered, even when power is applied to the Mars EB1 base board. -
Page 26: Vcc_Io Jumper Positions - Pin Numbering And Configuration Example
Jumper Position Function Description J1200 VCC_2V5 selected VCC_2V5 is connected to VCC_IO_B J1200 VCC_3V3 selected VCC_3V3 is connected to VCC_IO_B J1200 VCC_OUT selected Module VCC_OUT is connected to VCC_IO_B Table 19: Jumper Settings VCC_IO_B Figure 8: VCC_IO Jumper Positions - Pin Numbering and Configuration Example D-0000-307-001 26 / 39 Version 06, 22.07.2021... -
Page 27: Board Function
System controller System controller status, shared with SPI NOR flash CS signal Table 20: Board LEDs For details on the LED connections, refer to Section 6.10 and to the Mars EB1 Base Board User Schematics [5]. D-0000-307-001 27 / 39... -
Page 28: Buttons
All buttons are active-low; their function is described in Table 21. The user buttons can be configured by the user to have various functions. For details, refer to Section 6.10 and to the Mars EB1 Base Board User Schematics [5]. Button... -
Page 29: Dip Switches
DIP Switches There are two configuration switches on the Mars EB1 base board: CFG A and CFG B. Tables 22 and 23 describe their function; the factory default is marked in bold. For details on the board configuration, refer to the Mars EB1 Base Board User Schematics [5]. -
Page 30: S1200 - Configuration Switch B
Switch Signal Name Pos. Effect Comments The module USB signals are routed to the Refer to micro USB connector (front panel) CFG B 1 USBMOD_ID The module USB signals are routed to Section 6.5 the USB host connector On startup: BOOT_MODE1 is set to 1 After startup: The FTDI signals are routed to the micro USB connector (on side) -
Page 31: Ethernet
The Ethernet magnetics and the RJ45 connector are equipped on the base board, while the Ethernet PHY is equipped on the Mars module. The Ethernet port on the Mars EB1 base board can be used as 1 Gigabit Ethernet port or as 2 10/100 Mbit Ethernet ports, depending on the equipped Mars module. -
Page 32: Usb
6.5.2 USB 2.0 Device Controller (FTDI) The FTDI FT2232HQ USB 2.0 device controller present on the Mars EB1 base board can be used to easily implement a communication link to a host PC. The FTDI device is connected to the system controller and can be used for various communication protocols. -
Page 33: I2C Communication
I2C Communication There are several I2C devices on the Mars EB1 base board, connected to the I2C communication lines. These are presented in Table 25. Note that the I2C signals connected to the Mars connector address other I2C devices equipped on the Mars module. -
Page 34: User Eeprom
User EEPROM The Mars EB1 base board features a user EEPROM which may be accessed via I2C. It can be used to store user data (e.g. a serial number) and can be accessed by the FPGA and by the system controller. -
Page 35: Spi Nor Flash
SPI NOR Flash The SPI NOR flash is not equipped in the standard configuration of the Mars EB1 base board. The current system controller firmware does not support communication between the SPI NOR flash and the Mars module. 6.10 System Controller... -
Page 36: Operating Conditions
7 Operating Conditions Absolute Maximum Ratings Table 32 indicates the absolute maximum ratings for Mars EB1 base board. Symbol Description Rating Unit VCC_12V_IN Supply voltage relative to GND -0.5 to 16 Refer to the Mars VCC_IO_[x] VCC I/O input voltage relative to GND... -
Page 37: Ordering And Support
8 Ordering and Support Ordering Please use the Enclustra online request/order form for ordering or requesting information: http://www.enclustra.com/en/order/ Support Please follow the instructions on the Enclustra online support site: http://www.enclustra.com/en/support/ D-0000-307-001 37 / 39 Version 06, 22.07.2021... - Page 38 List of Figures Hardware Block Diagram ........Product Label .
- Page 39 [2] Enclustra FPGA Manager IP Solution http://www.enclustra.com/en/products/fpga-manager/ [3] Enclustra Display Controller IP Core http://www.enclustra.com/en/products/ip-cores/display-controller/ [4] Mars EB1 Base Board IO Net Length Excel Sheet Ask Enclustra for details [5] Mars EB1 Base Board User Schematics Ask Enclustra for details [6] Mars EB1 Base Board Known Issues and Changes...
