ORDERING INFORMATION

BILL OF MATERIALS

Table 11. Bill of Materials
Qty Components
50 3.3V, 5V, 6V, ADDR0, ADDR1,
AINN0, AINN1, AINN2, AINP0,
AINP1, AINP2, BCLK0, BCLK1,
D2.5V, DAC1P to DAC16P,
FSYNC0, FSYNC1, HPOUTN,
HPOUTP, MCLKO, MO, MP0, MP1,
MP2, MP22, MP23, MP24, MP25,
SCL, SDA, SDI0, SDI1, SDO0,
SDO1, TP1
1 A1
91 C1, C6, C8, C9, C10, C12, C14,
C27, C28, C32, C35, C37, C39,
C40, C43, C44, C47, C54, C56 to
C59, C90 to C92, C94, C95, C99,
C101, C107 to C111, C113, C115 to
C136, C142 to C171, C178, C181,
C201, C208
10 C7, C17 to C19, C93, C98, C100,
C104, C106, C112
17 C29, C34, C38, C41, C42, C45,
C46, C48, C51, C55, C102, C103,
C105, C114, C139 to C141
4 C11, C13, C15, C16
2 C137, C138
1 C172
3 C173, C176, C193
3 C174, C177, C187
10 C20, C21, C23 to C26, C175, C179,
C182, C183
1 C180
3 C3, C4, C184
1 C186
1 C189
1 C190
1 C191
1 C192
10 C194 to C198, C202, C204 to C207
2 C199, C200
2 C2, C5
1 C203
4 C30, C31, C33, C36
16 C49, C50, C62 to C75
analog.com
Description
White test point, connector PCB
Microprocessors supervisory circuit in 4-Lead SOT-143,
log
0.1 µF ceramic capacitors, 16 V, 10%, X7R, 0402,
AEC-Q200
1 µF ceramic capacitors, 16 V, 10%, X7R, 0603, AEC-
Q200
10 µF ceramic capacitors, 10 V, 20%, X5R, 0603, AEC-
Q200
Not recommended for new designs (NRND), 3.3
µF ceramic capacitors, 16 V, 20%, X6S, 0603, low
equivalent series resistance (ESR)
33 pF ceramic capacitors, 16 V, 5%, X7R, 0402, AEC-
Q200
4.7 µF ceramic capacitor, 50 V, 10%, X7R, 1206
1 µF ceramic capacitors, 50 V, 10%, X7R, 1206
0.1 µF ceramic capacitors, 50 V, 10%, X7R, 0603,
AEC-Q200, Low ESR
22 µF ceramic capacitors, 16 V, 10%, X7R, 1210
1000 pF ceramic capacitors, 50 V, 5%, C0G, 1206
4.7 µF ceramic capacitors, 16 V, 10%, X6S, 0603
10 µF ceramic capacitor, 50 V, –20% to +80%, Y5V,
1210
10 pF ceramic capacitor, 50 V, 0.5 pF, C0G, 0402
3300 pF ceramic capacitor, 50 V, 5%, C0G, 0603, AEC-
Q200, Low ESR
33 pF ceramic capacitor, 50 V, 5%, C0G, 0402, AEC-
Q200, Low ESR
47 µF ceramic capacitors, 10 V, 10%, X7R, 1210
2.2 µF ceramic capacitors, 10 V, 10%, X7R, 0603
0.01 µF ceramic capacitors, 25 V, 10%, X7R, 0402,
AEC-Q200
27 pF ceramic capacitors, 50 V, 5%, C0G, 0603
10 nF ceramic capacitor, 16 V, 5%, X7R, 0402
NRND, 04.7 µF ceramic capacitors, 6.3 V, 10%, X5R,
0603
2700 pF ceramic capacitors, 50 V, 5%, C0G, 0603
EVAL-ADAU1861
Manufacturer Manufacturer Number
Keystone Electronics 5002
Analog Devices, Inc. ADM811TARTZ-REEL7
Murata GCM155R71C104KA55D
Murata GCM188R71C105KA64D
Taiyo Yuden GRM188R61A106ME69D
TDK C1608X6S1C335M080AC
KEMET C0402C330J4RACAUTO
Murata GRM31CR71H475KA12L
AVX 12065C105KAT2A
TDK CGA3E2X7R1H104K080AA
Murata GRM32ER71C226KEA8L
AVX 12065A102JAT2A
Murata GRM188C81C475KE11D
AVX Corporation GCM32EC71H106KA03L
TDK CGA2B2C0G1H100D050BA
TDK CGA3E2C0G1H332J080AA
TDK CGA2B2C0G1H330J050BA
Murata GRM32ER71A476KE15L
Murata GRM188R71A225KE15D
Murata GCM155R71E103KA37D
PHYCOMP (Yageo) CC0603JRNP09BN270
AVX Corporation 0402YC103JAT2A
Murata GRM188R60J474KA01D
Murata GRM1885C1H272JA01D
