ORDERING INFORMATION
Table 11. Bill of Materials (Continued)
Qty Components
17 R48, R49, R53 to R66, R164
2 R3, R165
1 R167
1 R168
1 R169
1 R170
6 R21 to R24, R26, R27
7 R32, R39, R40, R42 to R45
2 R37, R88
1 R38
1 R5
16 R50, R51, R67 to R80
1 R52
4 R83, R84, R87, R89
1 R90
1 S1
2 S2, S3
1 S4
4 S5 to S8
10 TP4 to TP13
1 U1
1 U11
9 U6, U10, U12 to U18
4 U19 to U22
1 U2
15 U7, U23 to U36
1 U3
1 U37
1 U38
1 U39
1 U4
2 U40, U41
1 U42
1 U5
analog.com
Description
475 Ω SMD resistors, 1%, 1/10 W, 0603, AEC-Q200
12 kΩ SMD resistors, 1%, 1/16 W, 0402
7.5 kΩ SMD resistor, 0.1%, 0.15 W, 0603, AEC-Q200,
sulfur resistant
1.27 kΩ SMD resistor, 1%, 1/10 W, 060,3 AEC-Q200
40.25 kΩ SMD resistor, 1%, 1/10 W, 0603, AEC-Q200
13 kΩ SMD resistor, 1%, 1/10 W, 0603
1 kΩ SMD resistors, 1% 1/10 W, 0603, AEC-Q200
10 kΩ SMD resistors, 1% 1/10 W, 0603, AEC-Q200
49.95 kΩ SMD resistors, 1%, 1/10 W, 0603, AEC-Q200
1.5 kΩ SMD resistor, 1%, 1/10 W 0402, AEC-Q200
1 kΩ SMD resistor, 1%, 1/10 W, 0402, AEC-Q200
49.9 kΩ SMD resistors, 1%, 1/10 W, 0402, AEC-Q200
562 Ω SMD resistor, 1%, 1/10 W, 0402, AEC-Q200
100 kΩ SMD resistors, 1%, 1/10 W, 0603
100 Ω SMD resistor 5%, 1/10 W, 0402, AEC-Q200
Switch, slide, 4PDT
Switches, tactile, 6 mm GULLWING SMD
Switch, SPST, slide, 2-position
Switches, 4-postion slide dual in-line package (DIP)
Connector PCB, black test points
IC, CMOS 1K microwave serial EEPROM
IC, low-power 1.8 V, 128 MBIT, SPI/quad, serial,
nonvolatile storage flash
IC, 1-bit unidirectional translators
IC, bottom port, PDM, low power, multimode
microphone with high acoustic overload point mode
IC, quad, high-speed, USB to multipurpose UART,
multiprotocol synchronous serial engine
IC, transistor-to-transistor logic (TTL) translator 1-
channel bidirectional
IC, 16-channel, high performance, 192 kHz, 24-bit DAC Analog Devices
IC, 20 V, 200 mA, ultra-low noise, ultra-high power-
supply rejection ratio (PSRR) RF linear regulator
IC, 20 V, 500 mA, low noise LDO regulator with soft-
start
IC, 500 mA, low dropout, CMOS, linear regulator with
soft-start
IC, three analog-to-digital converters (ADCs), one DAC,
lowe power codec with audio digital-signal processors
(DSPs)
IC, 500 mA, low-dropout, CMOS, linear regulator with
soft-start
IC, low voltage supervisory circuit with watchdog in
4-Lead SC70
2
IC-CMOS I C bus repeater
EVAL-ADAU1861
Manufacturer Manufacturer Number
Panasonic ERJ-3EKF4750V/
RC0603FR-07475RL
Yageo RC0402FR-0712KL/
RC0402DR-0712KL
Vishay PAT0603E7501BST1/
RT0603DRE077K5L
Panasonic ERJ-3EKF1271V
Vishay CRCW060340K2FKEA/
AC0603FR-1340K2L
Yageo RC0603FR-0713KL
Panasonic ERJ-3EKF1001V
Panasonic ERJ-3EKF1002V
Panasonic ERJ-3EKF49R9V
Panasonic ERJ-2RKF1501X
Panasonic ERJ-2RKF1001X
Panasonic ERJ-2RKF4992X
Panasonic ERJ-2RKF5620X
Bourns CR0603-FX-1003ELF
Panasonic ERJ-2GEJ101X
TE Connectivity Ltd MSS420004
TE Connectivity Ltd FSM6JSMA
CTS Electronic 219-2LPSTR
Components
CTS Electronic 219-4LPST
Components
Keystone Electronics 5001
Microchip Technology 93LC46B/SN
WINBOND W25Q128JWEIQ
ONSEMI FXLP34L6X
TDK MMICT3902-00-012
FTDI FT4232HQ-REEL
NEXPERIA 74AVC1T45GN,132
ADAU1966AWBSTZ
Analog Devices LT3042IMSE#TRPBF
Analog Devices ADP7105ARDZ
Analog Devices ADP1715ARMZ-3.3-R7
Analog Devices ADAU1861BCSZ-RL
Analog Devices ADP1715ARMZ-R7
Analog Devices ADM8616WCYAKSZ-RL7
NXP Semiconductors PCA9517DP,118
Rev. 0 | 23 of 24
