USING THE EVALUATION BOARD
CONTROL PORT
The EVAL-ADAU1861EBZ is configured to SPI mode by default. It
also supports I2C and UART communications. Detailed connection
and jumpers please refer to
Table
Table 3. Control Port Jumper and Switch (S1) Settings
Communication Port
Switch S4 Address Setting
SPI
Not applicable
2
I
C
S4, default 0x64 (00), 0x65 (01), 0x66 (10),
0x67 (11)
UART
Not applicable
analog.com
3.
Jumper Settings
Jump JP28, JP27, JP1, and JP26 to the right side (SDA/MISO_B, SCL/
SCLK_B, ADDR1/MOSI_B, ADDR0/SS_B)
Jump JP28, JP27, JP1, and JP26 to the right side (SDA/MISO_B, SCL/
SCLK_B, ADDR1/MOSI_B, ADDR0/SS_B)
Jump JP28, JP27, JP1, JP26 to the left side (TX, GND, RXI, IOVDD)
EVAL-ADAU1861
Switch S1 Settings
Up (SPI)
2
Down (I
C)
Not applicable
Rev. 0 | 9 of 24
