User Guide
ORDERING INFORMATION
Table 11. Bill of Materials (Continued)
Qty Components
16 C52, C53, C76 to C89
1 C60
1 C61
2 C96, C97
2 D1, D2
1 DS1
2 E1, E6
4 E2,E3,E4,E5
1 F1
1 J1
19 JP1, JP5 to JP9, JP11, JP22, JP24
to JP30, JP38 to JP41
23 JP2 to JP4, JP10, JP12 to JP21,
JP23, JP31 to JP37, JP42
2 L1, L2
1 L3
1 L4
1 P1
12 P2 to P11, P13, P15
1 P12
1 P14
5 P16, P18 to P21
6 P17, P22 to P26
1 Q1
18 R1, R2, R4, R11, R14, R15, R28,
R81, R91 to R94, R97 to R99, R166
7 R6, R9, R10, R12, R13, R100, R101 2 kΩ SMD resistors, 1%, 1/10 W, 0603
4 R95, R96, R102, R103
25 R7, R8, R19, R20, R46, R104 to
R114, R127 to R134, R156
16 R115 to R122, R139 to R146
2 R153, R159
2 R154, R162
1 R158
3 R16 to R18
1 R161
1 R163
analog.com
Description
100 µF tantalum capacitors, 6.3 V, 10%, 3528-20
5600 pF ceramic capacitor, 25 V, 10%, X7R, 0402
390 pF ceramic capacitor, 50 V, 5%, C0G, 0402, AEC-
Q200
12 pF ceramic capacitors, 50 V, 5%, C0G, 0402
Diodes, Schottky, rectifier, surface-mount device (SMD) ONSEMI
Light-emitting diode (LED), SMD, 0603, green
Inductors, chip ferrite bead, 0.90 Ω DC resistance
maximum, 0.2 A
Inductor, ferrite bead, 0.52 Ω DCR, 0.3 A
Fuse reset polyswitch
Connector PCB, Powerjack mini, 0.08 inches, right
angle
Connector PCB, high temperature, 3-position male
headers, unshrouded, single-row, single-throw, 2.54 mm
pitch, 3.05 mm solder tail
Connector PCB, BERG jumpers, ST male two position,
1X, M000385
Inductors, RF ceramic chip
Inductor, surface-mount technology (SMT) power
Inductor, common-mode chock for large current, 0.013
Ω DCR, 6 A
Connector PCB, Micro-USB 2.0 right angle, 0.65 mm
pitch
Connector PCB, 3.5 mm, stereo mode, audio jack
stereo
Connector PCB, low profile header, dual row, 2.54 mm
pitch
Connector PCB, header male, ST, 2.54 mm pitch, 3.05
mm solder tail
Connector PCB, 8-position male headers, double row
ST, 2.54 mm pitch, 3.05 mm solder tail, 5.84 mm post
height
Connector PCB, 2-position male headers, unshrouded
single row ST, 2.54 mm pitch, 3.05 mm solder tail
PNP transistor medium power
10 kΩ SMD resistors, 1%, 1/10 W, 0402, AEC-Q200
2.4 kΩ SMD resistors, 1%, 1/10 W, 0603, AEC-Q200
0 kΩ SMD resistors, jumper, 1/10 W, 0603, AEC-Q200
47 kΩ SMD resistors, 0.5%, 1/16 W, 0402, AEC-Q200
high reliability
60.4 kΩ SMD resistors, 1%, 1/10 W, 0603
1 MΩ SMD resistors,, 1% 1/10 W, 0603, AEC-Q200
47.5 kΩ SMD resistor, 1%, 1/8 W, 0805, AEC-Q200
5.1 kΩ SMD resistors, 1%, 1/10 W, 0603, AEC-Q200
15 kΩ SMD resistor, 1%, 1/10 W, 0603
165 kΩ SMD resistor, 1%, 1/10 W, 0603, AEC-Q200
EVAL-ADAU1861
Manufacturer Manufacturer Number
AVX Corporation TAJB107K006RNJ
AVX Corporation 04023C562KAT4A
Murata GCM1555C1H391JA16D
Murata GJM1555C1H120JB01D
MBR0540T1G
LUMEX SML-LX0603GW-TR
Murata BLM31AJ601SH1L
TDK MMZ1005S601CTD25
TE Connectivity Ltd SMD300F-2
Switchcraft RAPC722X
Sullins YMC03SAAN/PRPC003SAAN-RC
Amphenol FCI 69157-102HLF/PREC001DAAN-RC
Johanson Technology, Inc. L-07CR10JV6T
Coilcraft MSS1048-103MLB
Murata DLW5BTM101SQ2L
Hirose ZX62-B-5PA(33)
CUI SJ-3523-SMT
3M N2520-6002-RB
Sullins PREC004SAAN-RC
Sullins YMC04DAAN/PR20204VBDN
Sullins PBC02SAAN/PREC001DAAN-RC
Diodes Inc. ZX5T953GTA
Panasonic ERJ-2RKF1002X
Yageo RC0603FR-072KL
Panasonic ERJ-3EKF2401V
Panasonic ERJ-3GEY0R00V
Panasonic ERA-2AED473X/AT0402FRE0747KL
Yageo RC0603FR-0760K4L
Panasonic ERJ-3EKF1004V
Panasonic ERJ-6ENF4752V
Panasonic ERJ-3EKF5101V
Yageo RC0603FR-0715KL
Panasonic ERJ-3EKF1653V
Rev. 0 | 22 of 24
