+CE1 kit (continued)
EC-C+CE1 KIT Order number 11297885
Part
BUSBAR, T=4, CLINCHED
BUSBAR, T=4, CLINCHED
BOLT. SOCKET HEAD- M6 x 12, DIN 912, Z]
WASHER D6, DIN 125
FILM T=0.375
FILM T=0.375
FILM T=0.375
BUSBAR, T=4, CLINCHED
BOLT. SOCKET HEAD- M8 X 20 (ISO 4762) Z]
STICKER, WARNING, CHARGED CAPACITORS MUL
+CE2 kit
EC-C+CE2 KIT Order number 11297886
Part
CABLE GLAND, M32X1,5 BG 232MS TRI EMC
PLUG, M25 x 1,5 PLITSCH ART. NO 7225 DRE
WASHER. LOCKING-, NORD-LOCK NL8SS
BOLT. SOCKET HEAD-, M8 X 20, DIN 912, A4
WASHER D5, DIN 125, A4
PLATE, T=3
BOLT. SOCKET HEAD-, M5 X 8, DIN 912, A4
ASSEMBLY. CABLING 10 MM2 CABLE ASSEMBLY
CABLE LUG, 10-6, WÜRTH 355710 6
CABLING, 10MM2, DRUSEIDT DRU15020 GR/GE,
ASSEMBLY PLATE WITH EXTRUDED GASKET
TERMINAL BOX MACHINING, MAX 3XM32
SEAL. WASHER-, USIT, M5, 5,7X10X1
BOLT. SOCKET HEAD-, M5 X 20, ISO 7380, Z
BOLT. SOCKET HEAD-, M5 X 30, ISO 7380, Z
BOLT. SOCKET HEAD-, M6 X 8, DIN 912, ZIN
CONNECTOR, STAND OFF INSULATOR ERIFLEX I
WASHER. LOCKING-, NORD-LOCK NL6
BOLT. SOCKET HEAD- M6 x 10, DIN 912, ZI]
STICKER, L3, PLATE WITH GLUE
STICKER, L2, PLATE WITH GLUE
STICKER, L1, PLATE WITH GLUE
SEAL. WASHER-, BONDED SEALS, U 6,7X10X1
FILM T=0.375
BUSBAR, T=4, CLINCHED
BUSBAR, T=4, CLINCHED
BUSBAR, T=4, CLINCHED
BOLT. SOCKET HEAD- M6 x 12, DIN 912, Z]
WASHER, D8 DIN 125
Quantity (pcs)
1
1
7
7
1
1
1
2
2
1
Quantity (pcs)
3
3
1
1
1
1
1
1
2
13
1
1
6
4
2
2
2
2
2
1
1
1
2
1
1
1
1
2
3
