User Guide
EC-C1700B-420
Aftersales
© Danfoss | June 2023
+DCE kit
EC-C+DCE KIT Order number 11273429
Part
MODULE. DC CONNECTIONS, EC-C+DCE
WASHER, D8 DIN 125
BUSBAR, OD=16, ID=8,3, L=32
BOLT. SOCKET HEAD-, M8 X 55, DIN 912, ZI
SPRING.DISC-, D8, DIN 2093, 8,2 X 16 X 0,9
CABLE GLAND, M25 X 1.5, BG 225MS TRI PFLIT
+CE1 kit
EC-C+CE1 KIT Order number 11297885
Part
WASHER. LOCKING-, NORD-LOCK NL8SS
BOLT. SOCKET HEAD-, M8 X 20, DIN 912, A4
WASHER D5, DIN 125, A4
PLATE, T=3
BOLT. SOCKET HEAD-, M5 X 8, DIN 912, A4
CABLE GLAND, M25 X 1.5, BG 225MS TRI PFLIT
SEAL. WASHER-, BONDED SEALS, U 6,7X10X1
STICKER, DC-, PLATE WITH GLUE
STICKER, DC+, PLATE WITH GLUE
STICKER, L3, PLATE WITH GLUE
STICKER, L2, PLATE WITH GLUE
STICKER, L1, PLATE WITH GLUE
BOLT. SOCKET HEAD- M6 x 10, DIN 912, ZI]
WASHER. LOCKING-, NORD-LOCK NL6
ASSEMBLY. CABLING 10 MM2 CABLE ASSEMBLY
CABLE LUG, 10-6, WÜRTH 355710 6
CABLING, 10MM2, DRUSEIDT DRU15020 GR/GE,
BOLT. SOCKET HEAD-, M5 X 20, ISO 7380, Z
BOLT. SOCKET HEAD-, M5 X 30, ISO 7380, Z
SEAL. WASHER-, USIT, M5, 5,7X10X1
BOLT. SOCKET HEAD-, M6 X20, ISO 7380, ZI
BOLT. COUNTERSUNK-, M5 X 20, DIN 7991, Z
TERMINAL BOX MACHINING, MAX 5 X M25
ASSEMBLY PLATE WITH EXTRUDED GASKET
BOLT. SOCKET HEAD-, M8 X 16 (ISO 4762) Z
WASHER, D8 DIN 125
SPRING.DISC-, D8, DIN 2093, 8,2 X 16 X 0,9
BOLT. SOCKET HEAD-, M8 X 25 DIN EN ISO 4
BOLT. COUNTERSUNK-, M6 X 16, DIN 7991, Z
WASHER, D6, DIN 137 A, ZINKED
CONNECTOR, STAND OFF INSULATOR ERIFLEX I
BLOCK, INSULATING, MACHINING
BUSBAR, T=4, CLINCHED
Quantity (pcs)
1
2
2
2
2
2
Quantity (pcs)
1
1
1
1
1
5
3
1
1
1
1
1
2
2
1
2
13
4
2
6
3
4
1
1
5
10
10
5
2
5
5
1
1
