User Guide
EC-C1700B-420
Installation
52 |
©
Danfoss | June 2023
Cable lug and cable gland assembly cross section
Example of the equipment needed for the assembly
Description
Assembly equipment
Torque key and
(example)
turnkey head
Key
Assembly example for a 70
Cable with nominal
2
mm
cable
cross-section of 70
mm
Cable lug
Cable gland
Screw
Washer
Washer
Manufacturer's homepage Art.No./Part No.
http://www.pflitsch.de
http://www.pflitsch.de
http://www.hubersuhner.com
2
http://www.druseidt.de
http://www.pflitsch.de
-
-
-
730N/10-50
SE30
HUBER+SUHNER Radox
Elastomer S, screened, single
core, automotive cable
(FHLR4GC13X)
Druseidt with narrow flange
03906
Pflitsch blueglobe TRI bg 225ms
tri
Pflitsch blueglobe TRI bg 232ms
tri (depending on option, see
option list)
DIN 912 M8x16
DIN 2093, 8,2 x 16 x 0,9
DIN 125 D8
BC454142332191en-000101
