System schematics
System component values
System option
Component
-L
Resistors R1 and R2 (isolation measurement)
Resistor R3 (discharge)
Capacitors C1 and C2 (Y-capacitors)
Capacitor C3
Isolation resistance from DC-link to enclosure
Value
240 MΩ
68 kΩ
3.3 nF
0.55 mF
120 MΩ
BC454142332191en-000101
