User Guide
EC-C1700B-420
Installation
©
Danfoss | June 2023
Product types
Basic product type
EC-C1700B-420-L+MC95+AFE95+UG95
EC-C1700B-420-L+MC130+AFE130+UG130
EC-C1700B-420-L+MC175+AFE175+UG175
EC-C1700B-420-L+MC210+AFE210+UG210
For more information, see appropriate chapters in this user guide and the product data sheets.
Low voltage connections
The durability of the X1-connector is limited to 10 installations / removals by the connector
manufacturer.
Always check the compatibility of the X1-connector and the counterpart. Never try to alter the
connector in any way. Contact Danfoss Service if unsure.
When powering OFF the electric device, use the POWER_ON input. The power supply (VIN_N
and/or VIN_P) can be disconnected, if desired, after time t
deactivation of POWER_ON (see Figure Disconnecting the power supply in this Chapter). A safe
value for t
min
See the correct signal connections and product specific pin-layout from product data sheets
at http://www.danfoss.com.
For information about the assembly of the control signal connectors, see the manufacturer's
web page.
Control signals (option dependent)
Basic device supports following CAN-protocol:
•
CANopen
•
SAE J-1939
CAN-protocols are alternatives and the choice should be made when placing an order.
The control signals of the electric device are operated with the X1-connector.
To make sure of correct operation of the control signal, use compatible connector interface (male/
female) and appropriate shielded wiring.
Nominal power [kVA]
100
150
200
250
is 5 seconds.
Nominal current [A
]
RMS
95
130
175
210
has elapsed from the
min
BC454142332191en-000101 | 55
