User Guide
EC-C1700B-420
Installation
©
Danfoss | June 2023
Electrical connections
1
X1-connector (Low voltage connector for measurement data and control signals)
2
X2-connector (maintenance connector)
3
DC+
4
DC-
5
L3
6
L2
7
L1
