User Guide
EC-C1700B-420
Installation
© Danfoss | June 2023
Example of the equipment needed for the assembly (continued)
Description
Assembly example for a 50 Cable with nominal
2
mm cable cross-section of 50
mm
Cable lug
Cable gland
Screw
Washer
Washer

Cabling and wiring

Route the power cables as far from the control signal wires as possible. The minimum
separating distance is 100 mm. The crossings must be in an angle of 90º. Power cables and
control wires should be routed near the frame of the application. Make sure that all terminal
connections are tightened correctly.
Install the electric device by the instructions. Make sure that all the applications of the system, for
example, batteries are connected to the electric device by the instructions of this user guide and the
product specific guidelines.
Cabling
•
It is mandatory to use screened power cables. Cable selection must be based on application
requirements.
•
Select cable cross section depending on the cable gland size and the application requirements, like
maximum current.
•
Use only EMI-shielded power cables to make sure the correct operation of the electric device and to
minimize the radiated emissions. Cable shields must be connected to the electric device ground at
both ends of the cable.
Wiring
To ensure correct and steady operation, use EMI-shielded cables for the control signals of the electric
device. Cable shields must be connected to the electric device ground at both ends of the cable.
Recommendations for control signal cables
Cable
Resolver cabling
Other signals
External temperature measurement (PT100/PT1000)
User I/O cabling
Manufacturer's homepage Art.No./Part No.
http://www.hubersuhner.com
2
http://www.druseidt.de
http://www.pflitsch.de
-
-
-
HUBER+SUHNER Radox
Elastomer S, screened, single
core, automotive cable
(FHLR4GC13X)
Druseidt with narrow flange
03903
Pflitsch blueglobe TRI bg 225ms
tri
Pflitsch blueglobe TRI bg 232ms
tri (depending on option, see
option list)
DIN 912 M8x16
DIN 2093, 8,2 x 16 x 0,9
DIN 125 D8
Cable type and properties
shielded cable (twisted pair)
shielded multistrand wire
shielded cable (twisted pair)
shielded cable (twisted pair)
