User Guide
EC-C1700B-420
Installation
56 |
©
Danfoss | June 2023
Control signal connector information
Description
X1-Control signal connector (in the chassis)
Tyco Electronics/AMPSEAL, 35-pin (male)
X1-Cable connector (mating connector)
Tyco Electronics/AMPSEAL, 35-pin (female)
Make sure that the part number ends with -1 and not with any other number.
Tools and accessories
Description
Crimping Tool Assembly 58529-1 with Die
Assembly 58529-2
Connector seal plug (for storage and
transportation)
35-position wire relief
Detailed and up to date information can be found at manufacturer's web-pages. Connector assembly
according to connector manufacturer instructions (for example contact crimping).
Minimum wiring and connections needed for powering the electric device are shown below (marked
with red). If any of these signals is not connected, the electric device will not be switched on or it will be
in the tripped state and will not work.
Part number
Supplier example
1-776163-1
http://www.te.com/usa-en/
product-1-776163-1.html
Case:776164-1
http://www.te.com/usa-en/
product-776164-1.html
Pins: 770854-3 (wire
http://www.te.com/usa-en/
2
0.5-1.25mm
)
product-770854-3.html
Part number Supplier example
58529-1
http://fi.mouser.com/ProductDetail/TE-Connectivity/
58529-1/?qs=Xf%252b3Aw93yEM%2FQReWIgzu%252bw
%3D%3D
770678-1
http://www.te.com/usa-en/product-770678-1.html
http://www.te.com/usa-en/product-776463-1.html
776463-1
BC454142332191en-000101
