Roland VC-2 Owner's Manual page 90

Effects List
04: Stereo Echoes
Stereo reverb which simulates echoes.
Parameter Value
Pre Low Freq 50–4000 Hz
Pre Low Gain -15– +15 dB
Pre Mid Freq 50–20000 Hz
Pre Mid Q 0.5, 0.7, 1.0, 2.0,
4.0, 8.0
Pre Mid Gain -15– +15 dB
Pre Hi Freq 2000–20000 Hz
Pre Hi Gain -15– +15 dB
Pre Delay 0–500 ms
Repeat Time 20–500 ms
Rev Time 0.06–10.00 sec
LfDamp Gain -36–0 dB
HfDamp Gain -36–0 dB
05: Stereo Room
Stereo reverb which simulates the reverberation within a
room.
Parameter Value
Pre Low Freq 50–4000 Hz
Pre Low Gain -15– +15 dB
Pre Mid Freq 50–20000 Hz
Pre Mid Q 0.5, 0.7, 1.0, 2.0,
4.0, 8.0
Pre Mid Gain -15– +15 dB
Pre Hi Freq 2000–20000 Hz
Pre Hi Gain -15– +15 dB
Pre Delay 0–160.0 ms
Room Size 0–5
Rev Time 0.40–10.00 sec
LfDamp Gain -36–0 dB
HfDamp Gain -36–0 dB
90
Description
Frequency of the low range
Gain of the low range
Frequency of the middle range
Width of the middle range
Set a higher value for Q to nar-
row the range to be affected.
Gain of the middle range
Frequency of the high range
Gain of the high range
Adjusts the delay time from the
direct sound until the reverb
sound is heard.
Repeat interval
Duration (time) of the reverb
Degree of Low Damp
The Low Damp function damps
the low frequency band of the re-
verb sound quicker than other
bands.
Degree of High Damp
High Damp, by attenuating the
higher frequencies first.
Description
Frequency of the low range
Gain of the low range
Frequency of the middle range
Width of the middle range
Set a higher value for Q to nar-
row the range to be affected.
Gain of the middle range
Frequency of the high range
Gain of the high range
Adjusts the delay time from the
direct sound until the reverb
sound is heard.
Size of the room which is simu-
lated
Duration (time) of the reverb
Degree of Low Damp
The Low Damp function damps
the low frequency band of the re-
verb sound quicker than other
bands.
Degree of High Damp
High Damp, by attenuating the
higher frequencies first.
06: Stereo Cathedral
Stereo reverb which simulates the reverberation within a
cathedral.
Parameter Value
Pre Low Freq 50–4000 Hz
Pre Low Gain -15– +15 dB
Pre Mid Freq 50–20000 Hz
Pre Mid Q 0.5, 0.7, 1.0, 2.0,
4.0, 8.0
Pre Mid Gain -15– +15 dB
Pre Hi Freq 2000–20000 Hz
Pre Hi Gain -15– +15 dB
Pre Delay 0–160.0 ms
Room Size 0–5
Rev Time 0.40–10.00 sec
LfDamp Gain -36–0 dB
HfDamp Gain -36–0 dB
07: Stereo Church
Stereo reverb which simulates the reverberation within a
church.
Parameter Value
Pre Low Freq 50–4000 Hz
Pre Low Gain -15– +15 dB
Pre Mid Freq 50–20000 Hz
Pre Mid Q 0.5, 0.7, 1.0, 2.0,
4.0, 8.0
Pre Mid Gain -15– +15 dB
Pre Hi Freq 2000–20000 Hz
Pre Hi Gain -15– +15 dB
Pre Delay 0–160.0 ms
Room Size 0–5
Rev Time 1.00–10.00 sec
LfDamp Gain -36–0 dB
HfDamp Gain -36–0 dB
Description
Frequency of the low range
Gain of the low range
Frequency of the middle range
Width of the middle range
Set a higher value for Q to nar-
row the range to be affected.
Gain of the middle range
Frequency of the high range
Gain of the high range
Adjusts the delay time from the
direct sound until the reverb
sound is heard.
Size of the room which is simu-
lated
Duration (time) of the reverb
Degree of Low Damp
The Low Damp function damps
the low frequency band of the re-
verb sound quicker than other
bands.
Degree of High Damp
High Damp, by attenuating the
higher frequencies first.
Description
Frequency of the low range
Gain of the low range
Frequency of the middle range
Width of the middle range
Set a higher value for Q to nar-
row the range to be affected.
Gain of the middle range
Frequency of the high range
Gain of the high range
Adjusts the delay time from the
direct sound until the reverb
sound is heard.
Size of the room which is simu-
lated
Duration (time) of the reverb
Degree of Low Damp
The Low Damp function damps
the low frequency band of the re-
verb sound quicker than other
bands.
Degree of High Damp
High Damp, by attenuating the
higher frequencies first.
