Creating/Editing Patches (Patch Mode)
LIMITER
Parameter Value Explanation
Thres -40– Specifies the level (threshold level) at
(Threshold 0 dB which the limiter will begin to function.
Level)
Attack (At- 0–127 Specifies the time from when the input
tack Time) level exceeds the threshold level until the
limiter begins to operate.
Release 0–127 Specifies the time from when the input
(Release level drops below the threshold level until
Time) the limiter turns off.
Ratio 2:1– Specifies the compression ratio.
INF:1
Level (Out- 0–127 Adjusts the volume of the mic.
put Level) * This is linked with MIC Level in the top
screen.
NOISE SUP
Noise suppressor settings can be made.
For the parameters of the three-band equalizer, refer to
the explanation of OFF (p. 23).
NOISE SUPRESSOR
Parameter Value
Thres -60–0 dB
(Threshold
Level)
Release 0–127
(Release
Time)
Level (Out- 0–127
put Level)

Carrier Screen

You can go to the top screen by touching <Carrier> in the
lower part of the screen.
Patches whose patch algorithm is Poly PShift do not
have this screen.
The carrier screen will be different if the patch algorithm
is Processor~. Refer to "Carrier Screen for Processor~
Patch Algorithms" (p. 27).
24
Explanation
Specifies the level at which the noise
suppressor will begin to operate. When
the signal falls below the specified lev-
el, it will be muted.
Specifies the time from when the noise
suppressor begins to operate until the
volume reaches 0.
Adjusts the volume of the mic.
* This is linked with MIC Level in the
top screen.

OSC

OSC 1/OSC 2
The following parameters will be displayed if the oscillator
type is Analog.
Parameter Value Explanation
Wave — Selects the wave.
* The available waves will depend on the
patch algorithm.
Level 0–127 Adjusts the output volume.
Pan L64– Specifies the pan of the patch. "L64" is far
0–63R left, "0" is center, and "63R" is far right.
Pulse -63– Specifies the amount by which the wave
Width +63 shape will be modified.
SubOSC OFF, The same wave will be layered.
-2, OFF: No sound.
-1, -2: The second wave will sound two oc-
0 taves below.
-1: The second wave will sound one octave
below.
0: The second wave will sound at the same
pitch.
SubLvl 0–127 Specifies the output volume of the second
wave.
Detune -63– Specifies the amount of detuning for the
+63 second wave.
The following parameters will be displayed if the oscillator
type is PCM.
Parameter Value Explanation
Wave — Selects the wave.
* The available waves will depend on the
patch algorithm.
Level 0–127 Adjusts the output volume.
Pan L64– Specifies the pan of the patch. "L64" is far
0–63R left, "0" is center, and "63R" is far right.
Offset 0–15 Adjusts the precise point at which the
wave is to begin sounding.
