CyberData 011579 Installation Quick Reference

Mounting
The SIP Paging 25V/70V Amplifier has two mounting options:
1. Desktop - Included with the unit are rubber mounting feet that can be placed on the bottom of the
These rubber feet are meant for use when the unit is placed on a desktop or shelf.
2. Rackmount - Included with each unit are mounting ears to mount the
should be compatible with most standard rackmount systems. Please note the hardware to mount to the rackmount system is unique
to the rackmount enclosure and this hardware is not included. Each of the units also has multiple mounting holes on the side to mount
standard rail systems. For more details please visit our website or review the Operations Guide.
Desktop Version with Rubber Feet
Rack Tower Installation
1. Install the Sliding onto the Rack Tower.
Mounting Screw & Snap-Nuts
are not Provided
(Typically comes with Slides)
Sliding Rack and Tower are not provided
© 2023, CyberData Corporation, ALL RIGHTS RESERVED
SIP Paging 25V/70V Amplifier
SIP Paging 25V/70V Amplifier unit. The mounting hardware
2. Install the device onto the Sliding.
Mounting Screws and Snap-Nuts are not provided
(Typically comes with the Sliding)
931994A Quick Reference
unit. The IP Endpoint Company
Getting Started
• Be sure that you have received all the parts described in the
• Download the Operations Guide for the SIP Paging 25V/70V Amplifier at the following website:
https://www.cyberdata.net/pages/011579/
• WARNING: This product should be installed by a licensed electrician according to all local electrical and building codes.
• WARNING: To prevent injury, the product should be securely attached to a rackmount system or firmly on a desk with the included
rubber feet.
Parts List
(1) SIP Paging 25V/70V Amplifier
Contacting CyberData
Corporate Headquarters
CyberData Corporation
3 Justin Court
Monterey, CA 93940, USA
Phone: 831-373-2601
Fax: 831-373-4193
https://www.cyberdata.net/
Quick Reference
Installation Quick Reference
SIP Paging 25V/70V Amplifier
011579
Parameter Factory Default Setting
IP Addressing DHCP
a
IP Address 192.168.1.23
Web Access Username admin
Web Access Password admin
a
Subnet Mask 255.255.255.0
a
Default Gateway 192.168.1.1
a. Default if there is not a DHCP server present.
Parts List section.
(1) Power cord (2) Accessory Kit Terminal Blocks
Sales: 831-373-2601 ext. 334
Support: 831-373-2601 ext. 333
Support Website: https://support.cyberdata.net/
RMA Department Contact and Status: https://support.cyberdata.net/
Warranty Information: https://support.cyberdata.net/
931994A © 2023, CyberData Corporation, ALL RIGHTS RESERVED
(6) Rubber Feet
