Operating Guide | VLT® Refrigeration Drive FC 103

9.6.9 Relay Outputs

Programmable relay outputs
Maximum wire cross-section to relay terminals
Minimum wire cross-section to relay terminals
Length of stripped wire
Relay 01 terminal number
Maximum terminal load (AC-1)
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
Maximum terminal load (DC-13)
Maximum terminal load (AC-1)
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
Maximum terminal load (DC-13)
Minimum terminal load on 1–3 (NC), 1–2 (NO)
Environment according to EN 60664-1
Relay 02 terminal number
Maximum terminal load (AC-1)
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
Maximum terminal load (DC-13)
Maximum terminal load (AC-1)
Maximum terminal load (AC-15)
Maximum terminal load (DC-1)
Maximum terminal load (DC-13)
Minimum terminal load on 4–6 (NC), 4–5 (NO)
Environment according to EN 60664-1
1
IEC 60947 parts 4 and 5.
2
Overvoltage Category II
3
UL applications 300 V AC 2 A.
The relay contacts are galvanically isolated from the rest of the circuit by reinforced isolation (PELV).

9.6.10 Control Card, +10 V DC Output

Terminal number
Output voltage
Maximum load
The 10 V DC supply is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
Danfoss A/S © 2020.01
(1)
on 1–2 (NO) (Resistive load)
(1)
1–2 (NO) (Inductive load @ cosφ 0.4)
(1)
on 1–2 (NO) (Resistive load)
(1)
on 1–2 (NO) (Inductive load)
(1)
on 1–3 (NC) (Resistive load)
(1)
1–3 (NC) (Inductive load @ cosφ 0.4)
(1)
on 1–3 (NC) (Resistive load)
(1)
on 1–3 (NC) (Inductive load)
(1)
on 4–5 (NO) (Resistive load)
(1)
4–5 (NO) (Inductive load @ cosφ 0.4)
(1)
on 4–5 (NO) (Resistive load)
(1)
on 4–5 (NO) (Inductive load)
(1)
on 4–6 (NC) (Resistive load)
(1)
4–6 (NC) (Inductive load @ cosφ 0.4)
(1)
on 4–6 (NC) (Resistive load)
(1)
on 4–6 (NC) (Inductive load)
(2) (3)
(2) (3)
Specifications
2.5 mm
0.2 mm
1–3 (break), 1–2 (make)
24 V DC 10 mA, 24 V AC 2 mA
Overvoltage category III/pollution degree 2
4–6 (break), 4–5 (make)
24 V DC 10 mA, 24 V AC 2 mA
Overvoltage category III/pollution degree 2
AQ275652766279en-000101 / 130R0707| 137
2
2
(12 AWG)
2
(30 AWG)
8 mm (0.3 in)
400 V AC, 2 A
240 V AC, 0.2 A
80 V DC, 2 A
24 V DC, 0.1 A
240 V AC, 2 A
240 V AC, 0.2 A
50 V DC, 2 A
24 V DC, 0.1 A
400 V AC, 2 A
240 V AC, 0.2 A
80 V DC, 2 A
24 V DC, 0.1 A
240 V AC, 2 A
240 V AC, 0.2 A
50 V DC, 2 A
24 V DC, 0.1 A
50
10.5 V ±0.5 V
25 mA
