Operating Guide | VLT® Refrigeration Drive FC 103
96 (3.8)
154 (6.1)
1
1209 (47.6)
4X 73 (2.8)
69 (2.7)
1 Heat sink access panel (optional)
Illustration 54:
Back View of E1h
142 | Danfoss A/S © 2020.01
412 (16.2)
18 (0.7)
206
(8.1)
4X 457 (18.0)
464 (18.3)
168 (6.6)
1800 (70.9)
168 (6.6)
601 (23.7)
AQ275652766279en-000101 / 130R0707
