Operating Guide | VLT® Refrigeration Drive FC 103
Table 45: Electrical Data, Mains Supply 3x525–690 V AC
FC 103
High/normal overloadHigh overload=150% or 160% torque
for a duration of 60 s. Normal overload=110% torque for a du-
ration of 60 s.
Typical shaft output at 525 V [kW]
Typical shaft output at 575 V [hp]
Typical shaft output at 690 V [kW]
Enclosure size
Output current (3-phase)
Continuous (at 525 V) [A]
Intermittent (60 s overload) (at 525 V) [A]
Continuous (at 575/690 V) [A]
Intermittent (60 s overload) (at 575/690 V) [A]
Continuous kVA (at 525 V) [kVA]
Continuous kVA (at 575 V) [kVA]
Continuous kVA (at 690 V) [kVA]
Maximum input current
Continuous (at 525 V) [A]
Continuous (at 575/690 V) [A]
Maximum number and size of cables per phase (E1h/E2h)
- Mains and motor without brake [mm
- Mains and motor with brake [mm
2
- Brake or regen [mm (AWG)]
Maximum number and size of cables per phase (E3h/E4h)
2
- Mains and motor [mm (AWG)]
2
- Brake [mm (AWG)]
- Load share or regen [mm
Maximum external mains fuses [A]
Estimated power loss at 600 V [W]
Estimated power loss at 690 V [W]
Efficiency (3)
Output frequency [Hz]
Heat sink overtemperature trip [°C (°F)]
Control card overtemperature trip [°C (°F)]
Power card overtemperature trip [°C (°F)]
Danfoss A/S © 2020.01
2
(AWG)]
2
(AWG)]
2
(AWG)]
(1)
(2) (3)
(2) (3)
N630
NO
500
650
630
E1h/E3h
630
693
630
693
573
627
753
607
607
5x240 (5x500 mcm) 6x240 (5x500 mcm)
4x240 (4x500 mcm) 5x240 (4x500 mcm)
2x185 (2x350 mcm) 2x185 (2x350 mcm)
6x240 (6x500 mcm) 6x240 (6x500 mcm)
2x185 (2x350 mcm) 2x185 (2x350 mcm)
4x185 (4x350 mcm) 4x185 (4x350 mcm)
800
8676
8915
0.98
0–590
110 (230)
80 (176)
85 (185)
AQ275652766279en-000101 / 130R0707| 131
Specifications
N710 N800
NO NO
560 670
750 950
710 800
E2h/E4h E2h/E4h
763 889
839 978
730 850
803 935
694 808
727 847
872 1016
735 857
704 819
6x240 (5x500 mcm)
5x240 (4x500 mcm)
2x185 (2x350 mcm)
6x240 (6x500 mcm)
2x185 (2x350 mcm)
4x185 (4x350 mcm)
1200 1200
9709 11848
10059 12253
0.98 0.98
0–590 0–590
110 (230) 110 (230)
80 (176) 80 (176)
85 (185) 85 (185)
