Danfoss VLT FC 103 Operating Manual page 153
Refrigeration drive 355-800 kw, enclosure sizes e1h-e4h
Hide thumbs
Also See for VLT FC 103:
- Installation manual ,
- Programming manual (234 pages) ,
- Operating (182 pages)
Table of Contents
Advertisement
Operating Guide | VLT® Refrigeration Drive FC 103
262
(10.3)
1 RFI shield termination (standard with RFI option)
3 Cable entry plate
Illustration 63:
RFI Shield Termination and Cable Entry Plate Dimensions for E3h
Danfoss A/S © 2020.01
19 (0.7)
2X 219 (8.6)
2X 220
(8.6)
160
(6.3)
1
2
2 Cable/EMC clamp
AQ275652766279en-000101 / 130R0707| 151
Specifications
163
(6.4)
294
(11.6)
3
