Operating Guide | VLT® Refrigeration Drive FC 103
262
(10.3)
19 (0.7)
2X 220
1 RFI shield termination (standard with RFI option)
3 Cable entry plate
Illustration 67:
RFI Shield Termination and Cable Entry Plate Dimensions for E4h
Danfoss A/S © 2020.01
2X 268 (10.6)
(8.6)
160
(6.3)
1
2
2 Cable/EMC clamp
AQ275652766279en-000101 / 130R0707| 155
Specifications
163
(6.4)
294
(11.6)
3
