Operating Guide | VLT® Refrigeration Drive FC 103
5.7 E1h Terminal Dimensions
6X
613 (24.1)
1
515 (20.3)
485 (19.1)
200 (7.9)
0 (0.0)
1 Mains terminals
3 Motor terminals
Illustration 21:
E1h Terminal Dimensions (Front View)
46 | Danfoss A/S © 2020.01
2 Brake or regen terminals
4 Ground terminals, M10 nut
Terminal dimensions
Electrical Installation
2
721 (28.4)
3
4
AQ275652766279en-000101 / 130R0707
