Operating Guide | VLT® Refrigeration Drive FC 103
Illustration 30: E4h Load Share/Regen Terminal Dimensions (Side Views)

5.11 Control Wiring

5.11.1 Control Cable Access

All terminals to the control cables are inside the drive below the LCP. To access, either open the door or remove the front panel.
Danfoss A/S © 2020.01
2X 125 (4.9)
0 (0.0)
20 (0.8)
0 (0.0)
35(1.4)
Electrical Installation
A
8X 14 (0.5)
AQ275652766279en-000101 / 130R0707| 55
A
