Operating Guide | VLT® Refrigeration Drive FC 103
Illustration 24:
E2h Terminal Dimensions (Side Views)
Danfoss A/S © 2020.01
649 (25.5)
0 (0.0)
5X
14 (0.5)
44 (1.8)
0 (0.0)
36 (1.4)
649 (25.5)
0 (0.0)
A
Electrical Installation
AQ275652766279en-000101 / 130R0707| 49
A
