Operating Guide | VLT® Refrigeration Drive FC 103

3.2 Interior View of Enclosure E1h/E2h

1
2
3
4
5
6
1 Control shelf (see
illustration
3 RFI filter (optional)
5 Mains terminals
7 Fan power card
Danfoss A/S © 2020.01
4)
+ REGEN 82 - REGEN 83
FASTENER TORQUE: FASTENER TORQUE:
M10 19Nm (14FT-LB) M10 19Nm (14FT-LB)
M12 35Nm (26FT-LB) M12 35Nm (26FT-LB)
2 Local control panel (LCP) cradle
4 Mains fuses (required for UL Compliance, but otherwise
optional)
6 RFI shield termination
AQ275652766279en-000101 / 130R0707| 13
Product Overview
7
8
9
10
11
12
