Operating Guide | VLT® Refrigeration Drive FC 103
653
(25.7)
75
22 (0.8)
1
22 (0.8)
1 Cable entry plate
Illustration 59:
Door Clearance and Cable Entry Plate Dimensions for E2h
Danfoss A/S © 2020.01
871 (34.3)
A
137
(5.4)
508 (20.0)
656 (25.8)
424
(16.7)
184
(7.3)
17 (0.7)
656 (25.8)
Specifications
A
14 (0.6)
11 (0.4)
293 (11.5)
173 (6.8)
AQ275652766279en-000101 / 130R0707| 147
