Power supply

The STM32G474E-EVAL board is designed to be powered by a 5 V DC power source. It
incorporates a precise PTC and TRANSIL to protect the board from damage due to a wrong
power supply. One of the following five 5 V DC power inputs can be used, upon appropriate
board configuration:
•
CN25 power jack:
Marked PSU on the board (JP12 jumper setting on E5V on the silkscreen). The positive
pole is on the center pin as illustrated in
The external power supply from the CN25 power jack is from 5 to 18 V input voltage.
The dedicated DC/DC regulator ST1S41PHR is used for about 5.2 V output voltage
and provided up to 3 A current.
• CN21 USB Micro-B receptacle of STLINK-V3E with enumeration:
Up to 500 mA can be supplied to the board (JP12 jumper setting on STLK on the
silkscreen).
Offers the enumeration feature described in
• CN21 USB Micro-B receptacle of STLINK-V3E without enumeration:
Up to 1000 mA can be supplied to the board directly without enumeration (JP12 jumper
setting on CHGR on the silkscreen).
•
CN22 USB Type-C
Marked TYPE-C on the board (JP12 jumper setting on U5V on the silkscreen). Up to
500 mA can be supplied to the board in this way.
•
Pin 49 of CN5 and pin 49 of CN6 extension connectors for custom daughterboard:
Marked 5V_D on the board (JP12 jumper setting on D5V on the silkscreen).
The LD6 green LED turns on when the voltage on the power line marked as 5 V is present.
All supply lines required for the operation of the components on the STM32G474E-EVAL
are derived from that 5 V line.
Table 5 describes the settings of all jumpers related to powering the STM32G474E-EVAL
and extension board. VDD_MCU is STM32G474QET6 digital supply voltage line. It can be
connected to a fixed 3.3 V or with an adjustable voltage regulator controlled by the RV3
potentiometer and producing a range of voltages between 1.62 V and 3.6 V.
