Connectors
6.6

CN12 and CN10 CAN1 and CAN2 connectors

Pin number
1
6.7

CN11 RS232 and RS485 connector

Terminal
1
2
3
4
5
46/66

Figure 13. CN10 or CN12 CAN connector (front view)

Table 29. CN10 or CN12 CAN connector

Description
CANL

Figure 14. CN11 RS232 and RS485 connector (front view)

Table 30. CN11 RS-232/RS-485 D-sub connector

Terminal name
NC
RS-232_RX (PA10)
RS-232_TX (PA9)
RS-485_A
GND
UM2514 Rev 5
1 2
Pin number
2 CANH
Terminal
6 RS-232_DSR (BOOT0)
7 NC
8 RS-232_CTS (NRST)
9 RS-485_B
- -
UM2514
MSv46052V1
Description
MS30720V1
Terminal name
