Connectors
Pin number
3
4
6
1
2
5
6.19

CN25 power connector

The STM32G474E-EVAL board can be powered from a DC 5 V to 18 V power supply via
the external power supply jack (CN25) shown in
positive.
6.20

CN27 STLINK-V3E programming connector

The CN27 connector is only used for embedded STLINK-V3E programming during board
manufacturing. It is not populated by default or end-user-oriented.
52/66

Figure 21. CN26 stereo headset with a microphone jack

Table 38. CN26 on-board audio jack connector

Description
GND
OUT_Right
OUT_Left
NC
NC
NC

Figure 22. CN25 power-supply connector (front view)

DC +5V
UM2514 Rev 5
4
1
6
3
2
Stereo headset with microphone pinning
GND
SPK_R (33 Ω typical)
SPK_L (33 Ω typical)
NA
Figure
22. The central pin of CN25 must be
GND
5
MS30721V1
UM2514
MSv46080V1
