Pin name
PD1 109
VSS_7 110
VDD_7 111
PD2 112
PD3 113
PD4 114
PD5 115
PD6 116
PD7 117
PB3 118
PB4 119
PB5 120
PB6 121
PB7 122
PB8-BOOT0 123
PB9 124
PE0 125
PE1 126
VSS_8 127
VDD_8 128
Table 41. STM32G474E-EVAL I/O assignment (continued)
Double motor control
STM32G474E-EVAL
-
-
-
MC1|MC2_PFC_Shunt-Down_TIM3_ETR
-
MC1_Encoder_B_TIM2_CH2
-
-
MC1_Encoder_Index_TIM2_CH3
-
-
-
-
MC2_STOP_TIM8_BKIN
-
-
-
-
-
-
STM32G474E-EVAL I/O assignment
UM2514 Rev 5
General-purpose features
STM32G474E-EVAL
FMC_D3
-
-
RS485_DIR
QSPI_BK2_NCS
FMC_NOE
FMC_NWE
Audio_SAI_SD_A
FMC_NE1
JTDO-TRACESWO
USBPD_CC2 || JTRST
CAN2_RX
USBPD_CC1
USBPD_VCONN_EN2
CAN1_RX || BOOT0
CAN1_TX
FMC_NBL0
FMC_NBL1
-
-
