STM32G474E-EVAL I/O assignment
Pin name
PC6 80
PC7 81
PG0 82
PG1 83
PG2 84
PG3 85
PG4 86
PC8 87
PC9 88
PA8 89
PA9 90
PA10 91
PA11 92
PA12 93
VSS_6 94
VDD_6 95
PA13 96
PF6 97
PA14 98
PA15 99
PC10 100
PC11 101
PC12 102
PG5 103
PG6 104
PG7 105
PG8 106
PG9 107
PD0 108
58/66
Table 41. STM32G474E-EVAL I/O assignment (continued)
Double motor control
STM32G474E-EVAL
MC2_PWM_TIM8_CH1
MC2_PWM_TIM8_CH2
-
-
-
-
-
MC2_PWM_TIM8_CH3
-
-
-
-
-
-
-
-
-
MC2_Encoder A_TIM5_CH1
-
MC1_Encoder_Index_TIM2_ETR
MC2_PWM_TIM8_CH1N
MC2_PWM_TIM8_CH2N
MC2_PWM_TIM8_CH3N
-
-
-
-
-
-
UM2514 Rev 5
General-purpose features
STM32G474E-EVAL
COMP6_OUT
MFX_WAKEUP
FMC_A10
FMC_A11
FMC_A12
FMC_A13
FMC_A14
BK_Driver_TIM3_CH3
LCD_CS
Audio_SAI_SCK_A
USBPD_DBCC1 || USART1_TX
USBPD_DBCC2 || USART1_RX
USB_DM
USB_DP
-
-
SWDIO-JTMS
Audio_INT
SWCLK-JTCK
JTDI
SmartCard_IO_USART3_TX
USBPD_Source_EN
SmartCard_CLK_USART3_CK ||
USBPD_FRSTX
FMC_A15
I2C3_SMBA
I2C3_SCL
I2C3_SDA
LED1
FMC_D2
